| Platform | Consumer |
| Architecture | Kepler |
| Generation | GeForce 600 |
| Previous Gen | GeForce 500 |
| Next generation | GeForce 700 |
| Interface | PCIe 3.0 x16 |
| Name | GK106S |
| Foundry | TSMC |
| Process Node | 28 nm |
| Transistors | 2540 million |
| Die Size | 221.0 mm² |
| Density | 11.5 /mm² |
| Cores | 768 |
| TMUs | 64 |
| ROPs | 16 |
| Technology | GDDR5 |
| Size | 1 GB |
| Bus | 128 bit |
| Bandwidth | 86.4 GB/s |
| Speed | 5.4 Gbps |
| Base clock | 993 MHz 928 MHz |
| Memory clock | 1350 MHz |
| 6-pin | 1 |
| TDP | 110 w |
| Recommended PSU | 300 w |
| DVI-D DL | 1 |
| DVI-I | 1 |
| Mini HDMI | 1 |
| Slots | 1.8 1 |
| Length | 230 mm |
| Height | 131 mm |
| Width | 35 mm |
| Weight | 435 g |
| GPUs▲ | Base clock▲ | Slots▲ | Length▲ | Height▲ | Width▲ |
|---|---|---|---|---|---|
| 993 MHz +7.0% | 1.8 | 230 mm | 131 mm | 35 mm |
