GPU
| Platform | Consumer |
| Architecture | Fermi 2.0 |
| Generation | GeForce 500 |
| Previous Gen | GeForce 400 |
| Next generation | GeForce 600 |
| Interface | PCIe 2.0 x16 |
| Name | GF110 |
| Foundry | TSMC |
| Process Node | 40 nm |
| Transistors | 3000 million |
| Die Size | 520.0 mm² |
| Density | 5.8 /mm² |
| Cores | 512 |
| TMUs | 64 |
| ROPs | 48 |
| SMs | 16 |
| Technology | GDDR5 |
| Size | 1.5 GB |
| Bus | 384 bit |
| Bandwidth | 192.4 GB/s |
| Speed | 4.0 Gbps |
| Base clock | 832 MHz 772 MHz |
| Shader clock | 1544 MHz |
| Memory clock | 1050 MHz 1002 MHz |
| 8-pin | 2 |
| TDP | 244 w |
| Recommended PSU | 600 w |
| DisplayPort | 1 |
| HDMI | 1 |
| DVI | 2 |
| Slots | 2.3 2 |
| Length | 305 mm |
| Height | 127 mm |
| Width | 45 mm |
| GPU▲ | Price▲ | Shader clock▲ | Slots▲ | Length▲ | Height▲ | Width▲ |
|---|---|---|---|---|---|---|
| 1632 MHz +5.7% | 2.6 | 289.5 mm | 152.4 mm | |||
| 1564 MHz +1.3% | 3 | 319 mm | 128 mm | 58 mm | ||
| 1544 MHz | 2.3 | 305 mm | 127 mm | 45 mm |
