| Name | Navi 21 |
| Foundry | TSMC |
| Process Node | 7 nm |
| Transistors | 26800 million |
| Die Size | 520.0 mm² |
| Density | 51.5 /mm² |
| Cores | 5120 |
| TMUs | 320 |
| ROPs | 128 |
| RT Cores | 80 |
| Technology | GDDR6 |
| Size | 16 GB |
| Bus | 256 bit |
| Infinity Cache | 128 MB |
| Bandwidth | 576.0 GB/s |
| Speed | 18.0 Gbps |
| Base clock | 1860 MHz |
| Game Clock | 2310 MHz 2100 MHz |
| Boost clock | 2532 MHz 2310 MHz |
| Memory clock | 2250 MHz |
| 6-pin | 1 |
| 8-pin | 2 |
| TDP | 420 w 335 w |
| Recommended PSU | 850 w 700 w |
| DisplayPort | 3 |
| HDMI | 1 |
| Slots | 2.3 3 |
| Length | 270 mm |
| Height | 130 mm |
| Width | 45 mm |
| GPUs▲ | Price▲ | Boost clock▲ | Slots▲ | Length▲ | Height▲ | Width▲ |
|---|---|---|---|---|---|---|
| 2324 MHz +0.6% | 2.8 | 330 mm | 140 mm | 56 mm | ||
 $1,404.00 | 2324 MHz +0.6% | 2.9 | 320 mm | 140.2 mm | 57.8 mm | |
| 2532 MHz +9.6% | 2.3 | 270 mm | 130 mm | 45 mm |
