Name: Sapphire TOXIC R9 270X OC
Brand: Sapphire
SKU: 11217-02

GPUs

AMD Radeon R9 270X

Sapphire TOXIC R9 270X OC

AMD Radeon R9 270X
Sapphire TOXIC R9 270X OC
11217-02
Specifications
Models
No reviews yet. Be the first to share your thoughts!
 Log in to write a review.

Specifications

Information
PlatformConsumer
ArchitectureGCN 1.0
GenerationVolcanic Islands
Previous GenSea Islands
Next generationPirate Islands
InterfacePCIe 3.0 x16
Core
NameCuracao
FoundryTSMC
Process Node28 nm
Transistors3 million
Die Size212.0 mm²
Density0.0 /mm²
GPU Core Config
Cores1280
Compute Units20
TMUs80
ROPs32
Memory
TechnologyGDDR5
Size2 GB
Bus256 bit
Bandwidth179.2 GB/s
Speed5.6 Gbps

Clocks
Base clock1100 MHz 1000 MHz
Boost clock1150 MHz 1050 MHz
Memory clock1400 MHz
Power
6-pin2
TDP180 w
Recommended PSU500 w
Display
DisplayPort1 1.2
HDMI1 1.4a
DVI2
Dimensions
Slots2
Length308 mm 241 mm
Height109 mm
Width36 mm

Models

GPUs▲	Boost clock▲	Slots▲	Length▲	Height▲	Width▲
Sapphire TOXIC R9 270X OC 11217-02	1150 MHz +9.5%	2	308 mm

Platform	Consumer
Architecture	GCN 1.0
Generation	Volcanic Islands
Previous Gen	Sea Islands
Next generation	Pirate Islands
Interface	PCIe 3.0 x16

Name	Curacao
Foundry	TSMC
Process Node	28 nm
Transistors	3 million
Die Size	212.0 mm²
Density	0.0 /mm²

Technology	GDDR5
Size	2 GB
Bus	256 bit
Bandwidth	179.2 GB/s
Speed	5.6 Gbps

Base clock	1100 MHz 1000 MHz
Boost clock	1150 MHz 1050 MHz
Memory clock	1400 MHz

Cores	1280
Compute Units	20
TMUs	80
ROPs	32

6-pin	2
TDP	180 w
Recommended PSU	500 w

DisplayPort	1 1.2
HDMI	1 1.4a
DVI	2

Slots	2
Length	308 mm 241 mm
Height	109 mm
Width	36 mm
