GPU
| Name | Navi 32 |
| Foundry | TSMC |
| Process Node | 5 nm |
| Transistors | 28100 million |
| Die Size | 346.0 mm² |
| Density | 81.2 /mm² |
| Cores | 3840 |
| TMUs | 240 |
| ROPs | 96 |
| RT Cores | 60 |
| Technology | GDDR6 |
| Size | 16 GB |
| Bus | 256 bit |
| Bandwidth | 624.1 GB/s |
| Speed | 19.5 Gbps |
| Base clock | 1624 MHz 1295 MHz |
| Game Clock | 2254 MHz 2124 MHz |
| Boost clock | 2565 MHz 2430 MHz |
| Memory clock | 2438 MHz |
| 8-pin | 2 |
| TDP | 260 w |
| Recommended PSU | 700 w 600 w |
| DisplayPort | 3 2.1 |
| HDMI | 1 2.1a |
| Slots | 2.9 |
| Length | 326 mm |
| Height | 126 mm |
| Width | 58 mm |
| GPU▲ | Price▲ | Boost clock▲ | Slots▲ | Length▲ | Height▲ | Width▲ |
|---|---|---|---|---|---|---|
| 2565 MHz +5.6% | 3 | 319.8 mm | 150.9 mm | 59.2 mm | ||
| 2475 MHz +1.9% | 2.6 | 267 mm | 130 mm | 51 mm | ||
 $898.87 | 2565 MHz +5.6% | 2.8 | 302 mm | 130 mm | 56 mm | |
| $629.99 | 2565 MHz +5.6% | 3.1 | 320 mm | 134.9 mm | 61.6 mm | |
| 2430 MHz | 2.5 | 274 mm | 125 mm | 50 mm | ||
| 2565 MHz +5.6% | 2.9 | 326 mm | 126 mm | 58 mm | ||
| 2430 MHz | 2.6 | 335 mm | 130 mm | 52 mm | ||
| 2430 MHz | 2.6 | 280 mm | 128.8 mm | 52.6 mm |
